A PUNCH-PACKING POWERHOUSE TRIMMED DOWN TO SIZE
Designed for effortless agility while maintaining 100% Ariens® ability, the Compact Sno-Thro® is designed to be easy enough to take out for a light dusting of snow and reliable enough to tackle up to 59 tons per hour if needed. A 2.5X Quick-Turn chute rotation throws the snow where you want it. Its 24” all-steel housing and serrated 11” auger chew through huge drifts with ease. Don’t let its convenient size fool you, there’s a lot of power packed into the Ariens Compact.
Overview
- Ariens AX 223CC engine with electric start
- Strong cast-iron gear case
- Compact, user-friendly design with Auto-Turn for easy operation
Specifications
| Title |
COMPACT 24 Auto
|
|---|---|
| Model Number |
920029
|
| Power Train | |
| Engine |
Ariens AX®
|
| Starting System |
120v / Electric
|
| Steering |
Auto-Turn
|
| Drive Type |
Disc-O-matic
|
| Speeds |
6 Forward/2 Reverse
|
| Tire Size |
15 In / 38.1cm
|
| Tire Type |
Directional Snow Tread
|
| Clearing Specs | |
| Clearing Width (in/cm) |
24 In / 60.9cm
|
| Housing Height |
20 In / 50.7cm
|
| Throwing Distance |
3 ft - 40 ft
|
| Chute Rotation |
2.5x Quick Turn
|
| Chute Turning Radius |
205
|
| Deflector Control |
In-Dash Lever
|
| Stage Type |
Two Stage
|
| Auger Diameter |
11 In / 27.9cm
|
| Auger Type |
Steel Serrated
|
| Impeller Profile |
Steel 3 Blade
|
| Impeller Diameter |
12 In / 30.4cm
|
| Skid Shoes |
Steel Reversible
|
| Scraper Bar |
Steel Adjustable
|
| Gear Case |
Cast Iron
|
| Dimensions | |
| Length |
53.3 In / 135.3cm
|
| Width |
26.4 In / 67cm
|
| Height |
44 In / 111.7cm
|
| Weight (assembled) |
187 lb / 84.8 kg
|
| Warranties | |
| Product Warranty |
3 years residential use. 90 days commercial use
|
| Gear Case Warranty |
5 Year Consumer, 1 Year Commercial
|
| Accessories | |
| Features at a Glance |
Light Type: Halogen
Handwarmers: Optional Remote Deflector Control: Standard Drift Cutters: Optional One Hand Interlock: Standard |
