A MEAN, SNOW-CLEARING MACHINE THAT ADAPTS TO ANYTHING WINTER THROWS ITS WAY
The Deluxe Series is consistently one of our best sellers because it has a history of knocking winter down a few notches. They’re easy to maneuver and control with their standard Auto-Turn™ steering and huge 14” serrated all-steel auger. A high 21” housing height devours the snow before throwing it up to 50 feet at a rate of 62-72 tons per hour. Various engines and machine widths make it easy to find the right unit for your property. Behind a Deluxe, you’re walking in the tire tracks of greatness.
Overview
- Wide 24” clearing width that moves 62 tons of snow per hour
- Powerful 254cc Ariens AX engine
- Premium features like Auto-Turn and an LED headlight
Specifications
| Title |
DELUXE 24
|
|---|---|
| Model Number |
921045
|
| Power Train | |
| Engine |
Ariens AX®
|
| Starting System |
120v / Electric
|
| Steering |
Auto-Turn
|
| Drive Type |
Disc-O-matic
|
| Speeds |
6 Forward/2 Reverse
|
| Tire Size |
16 In / 40.6cm
|
| Tire Type |
Directional Snow Tread
|
| Clearing Specs | |
| Clearing Width (in/cm) |
24 In / 60.9cm
|
| Housing Height |
21 In / 53.3cm
|
| Throwing Distance |
3 ft - 50 ft
|
| Chute Rotation |
2.5x Ice Drill
|
| Chute Turning Radius |
200
|
| Deflector Control |
In-Dash Lever
|
| Stage Type |
Two Stage
|
| Auger Diameter |
14 In / 35.5cm
|
| Auger Type |
Steel Serrated
|
| Impeller Profile |
Steel 3 Blade
|
| Impeller Diameter |
14 In / 35.5cm
|
| Skid Shoes |
Steel Reversible
|
| Scraper Bar |
Steel Adjustable
|
| Gear Case |
Cast Iron
|
| Dimensions | |
| Length |
58.6 In / 148.8cm
|
| Width |
26.4 In / 67cm
|
| Height |
45.3 In / 115cm
|
| Weight (assembled) |
245.5 lb / 111.3 kg
|
| Warranties | |
| Product Warranty |
3 years residential use. 90 days commercial use
|
| Gear Case Warranty |
5 Year Consumer, 1 Year Commercial
|
| Accessories | |
| Features at a Glance |
Light Type: LED
Handwarmers: Optional Remote Deflector Control: Standard Drift Cutters: Optional One Hand Interlock: Standard |
