THE VERSATILITY OF A WHEEL OR TRACK UNIT IN A SINGLE MACHINE.
An exclusive Ariens® technology, the RapidTrak™ system is an adjustable tracked or wheeled machine designed to provide users with unrivaled power and versatility for any condition. RapidTrak maintains traction even against high snow piles on hilly or slippery pavement while its wheeled setting provides quick, effortless maneuverability on flat surfaces. Its intuitive, user-friendly design allows operators to switch between settings in seconds.
Overview
- Easy push-button electric start Ariens® AX 369cc engine
- Wide 28" clearing width that moves 73 tons of snow per hour
- Ariens exclusive Rapidtrak™ technology is capable of tackling any terrain
Specifications
| Title |
PLATINUM 28 RAPIDTRAK SHO
|
|---|---|
| Model Number |
921057
|
| Power Train | |
| Engine |
Ariens AX®
|
| Starting System |
120v / Electric
|
| Steering |
Auto-Turn
|
| Drive Type |
Disc-O-matic
|
| Speeds |
6 Forward/2 Reverse
|
| Tire Type |
Directional Snow Tread
|
| Clearing Specs | |
| Clearing Width (in/cm) |
28 In / 71.1cm
|
| Housing Height |
21 In / 53.3cm
|
| Throwing Distance |
3 ft - 55 ft
|
| Chute Rotation |
Quick Turn
|
| Chute Turning Radius |
200
|
| Deflector Control |
In-Dash Lever
|
| Stage Type |
Two Stage
|
| Auger Diameter |
14 In / 35.5cm
|
| Auger Type |
Steel Serrated
|
| Impeller Profile |
High Speed Steel 3 Blade
|
| Impeller Diameter |
14 In / 35.5cm
|
| Skid Shoes |
Steel Reversible
|
| Scraper Bar |
Steel Adjustable
|
| Gear Case |
Cast Iron
|
| Dimensions | |
| Length |
58.5 In / 148.5cm
|
| Width |
29.9 In / 75.9cm
|
| Height |
45.3 In / 115cm
|
| Weight (assembled) |
283 lb / 128.3 kg
|
| Warranties | |
| Product Warranty |
3 years residential use. 90 days commercial use
|
| Gear Case Warranty |
5 Year Consumer, 1 Year Commercial
|
| Accessories | |
| Features at a Glance |
Light Type: LED
Reflective Decals: Standard Handwarmers: Standard Remote Deflector Control: Standard Drift Cutters: Optional Track Drive: Standard One Hand Interlock: Standard |
